◆產品設備優點 Product features
1. 規劃大氣(qi),外型(xing)美觀大氣(qi),安全感覺好(hao);
2. 可手動調(diao)節式漩風脫離器,能將可以(yi)選(xuan)擇研磨(mo)材料與細微(wei)煤塵脫離,好的研磨(mo)材料以(yi)后施用;
3. 一(yi)般零(ling)零(ling)部件的用于創新(xin)型(xing)進出口(kou)產品(pin),運行使用時間長;
4. 制作(zuo)產(chan)品工件單(dan)單(dan)從表面均勻的;
5. 多功位構思;運行員可同時運行噴砂。只能根據企業使用需求,可以選擇擇一鍵或智能 ;可按投資者的標準生產廠家!
1. Novel design , beautiful shape, good environmental protection effect;
2. Adjustable cyclone separator, can be used with tiny dust separation, good abrasive continue to use;
3. The main components uses the high quality import parts, long service life;
4. Machining surface evenly;
5. Program design; An operator can also operate sandblasting. we can choose manual or automatic according to customer needs.
◆可用于的范圍 Applicable scope
木板,筆(bi)記本電腦殼(ke)子,車(che)載音響(xiang)表面板,三文治烤盤等垂(chui)直(zhi)面及方(fang)體(ti)軸類的噴砂加工處理。
Plate, the computer case, music panels, sandwich baking dish wait for plane and workpiece of sandblasting processing.
◆通常技術性參數設置 Main technical parameters
|
儀器產品型號 Model |
STR-多工位輸送式噴砂機 |
|
電腦整機長寬 Complete machine size(mm) |
3000×1000×1700 |
|
工(gong)作的服(fu)務器 Work space(mm) |
2000×1000×800 |
|
外氣流輸送(song)長寬(kuan)比 Conveying the size(mm) |
500×1000×1000(2件) |
|
除灰箱厚度 Dedust box sizes(mm) |
600×600×1800 |
|
離心分離機直(zhi)流電(dian)機 Separator motor |
220V 50HZ 550W |
|
提取器功率(lv) Separator air volume |
8.5m3/min |
|
文件壓縮的空氣源 Compressed air source |
2-8bar(kg/cm2) |
|
噴槍 Spray gun |
2把 |
|
照明(ming) Floodlight |
兩盞30W防燃燈 |
|
機設備(bei)凈重 Machine weight |
550kg |
