◆車輛特別 Product features(請往前網頁瀏覽(lan)大有(you)量案列照(zhao)片圖片供符合)
噴砂機主要用于電鍍、噴漆、噴涂等所有被覆蓋加工前噴砂處理;舊樣翻新清洗;金屬制品及塑膠、水晶、玻璃等表面痕跡消除,啞光霧面處理,使產品表面提升檔次;機加工零件微小毛刺去除;增加金屬件表面硬度,消除應力如彈簧、機加工刀具等;金屬制品及非金屬制品表面刻蝕圖案、文字及防滑處理,如大理石、印章、手柄防滑等。本機應用范圍:適用于大量中小型一般工件及高硬度工件的快速噴砂。如發動機配件、閥門、熱處理工件等。該機型設計新穎,結構科學合理,操作方便,加工性能優越;噴砂速度快,撞擊點深。
Features: Sandblasting machine is mainly used in electroplating, paint, coating area to-be-covered before piating; Old way of refurbished cleaning; Metal products and plastic, crystal, glass surface trace eliminate scattered, dumb, surface process to enhance the grade of the product's surface; Machining parts tiny burrs purify; Increase the metal surface hardness, eliminate stress such as spring, mechanical cutters, etc.; Metal and non-metai products surface etching pattern, writing and prevent slippery processing, such as marble, seals, and handle prevent slippery, etc. The machine is applied the range: applicable to small and medium-sized general of workpiece and high hardness workpieces quickly sandblasting. Such as engine fittings, valves, heat treatment workpiece, etc. This machine has novel, scientific design and reasonable structure, convenient operation, processing superior performance; Gush arenaceous speed, the impact point at deep.
◆應用區域 Applicable scope
電(dian)子器材五金螺(luo)絲類,ABS氟塑料(liao),亞克(ke)力(li)板材,黑色(se)防靜電(dian)鑷子。中(zhong)重型產品、形式件、不(bu)飽和樹脂等產品或生產技術品噴砂(sha)。
Applicable scope: electronic hardware class, ABS plastic, acrylic, resin, workpiece or handicraft sandblasting
◆通常新技術性能 Main technical parameters供關聯性(xing)主要與(yu)金融業務聯絡
|
機主要參數(shu) Model |
STR-9070 |
STR-9080 |
STR-1010 |
STR-1212 |
|
做工作艙尺(chi)碼 Internal size(mm) |
900×700×790 |
900×800×700 |
1000×1000×670 |
1180×1180×980 |
|
整套(tao)裝置(zhi)厚度 Complete machine size(mm) |
900×700×1780 |
950×850×1720 |
1000×1000×2100 |
1200×1200×2580 |
|
吸塵箱的(de)尺寸(cun) Dedust box sizes(mm) |
600×600×1680 |
600×600×1680 |
600×600×1680 |
800×800×1780 |
|
電原 Power |
220V 50Hz |
220V 50Hz |
220V 50Hz |
220V 50Hz |
|
工具(ju)照明工作燈 Machine floodlight |
220V 20W 節省燈(deng) |
220V 20W 環保(bao)LED燈 |
220V 20W 能效(xiao)燈 |
220V 20W 節能環保燈 |
|
分離法器交流電(dian)動機 Separator motor |
220V 50Hz 0.55-3KW |
220V 50Hz 0.55 |
220V 50Hz 0.55-3KW |
220V 50Hz 0.55-3KW |
|
分離(li)法器排風量 Separator air volume |
8.5m3/min |
8.5m3/min |
8.5m3/min |
8.5m3/min |
|
縮短(duan)大氣(qi)源 Compressed air source |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
|
機(ji)氣(qi)容(rong)量 Weight |
380kg |
380kg |
400kg |
380kg |
